Custom length SPREADER beam - WLL 8,900 LBS - 27,600 LBS

Custom length SPREADER beam - WLL 8,900 LBS - 27,600 LBS - Image 2

Custom length SPREADER beam - WLL 8,900 LBS - 27,600 LBS - Image 3

Custom length SPREADER beam - WLL 8,900 LBS - 27,600 LBS - Image 4

Custom length SPREADER beam - WLL 8,900 LBS - 27,600 LBS - Image 5

Custom length SPREADER beam - WLL 8,900 LBS - 27,600 LBS - Image 6

Lifting, Rigging & Hoisting Equipment, Spreader Beams

Custom length SPREADER beam – WLL 8,900 LBS – 27,600 LBS

Manufacturer: Fortis Mining Engineering Manufacturing

Model #: 26616

Weight: 344 lbs

Working Load Limit (WLL): 8,900 lbs – 27,600 lbs

Assembly includes:

End Fittings
Middle Fitting (if required)
Pipe (based on required length)

Dimensions:

Min. Length: 4′
Max. Length: 20′
Height: 12 1/4″
Width: 6 13/16″

Features:

Engineered design
Meets applicable ASME standards
Manufactured in Canada

For additional rigging supplies, contact Northern Strands

Want to buy this product? Get in touch.

Request More Info

Want to make it custom? Certified Sales & Rentals and our colleagues at Fortis Mining & Engineering can design and build custom Lifting, Rigging & Hoisting Equipment, Spreader Beams that suit your specific needs.
