Specifications:

• Manufacturer: Darda
• Model: C12
• Required Hole Diameter: 1.77″ – 1.89″ (45mm – 48mm)
• Minimum Drill Depth: 24″ (610mm)
• Splitting Force (theoretical): 1,363,000 lb/ft (1847979.86 Nm)
• Effective Splitting Force: 789,000 lb/ft (1069740.36 Nm)
• Weight: 68 lbs (31kg)
• Length of Splitting Cylinder: 51″ (1290mm)
• Length of Wedge Set: 15″ (380mm)

Applications of Use:

• Splitting of concrete and reinforced concrete
• Splitting walls and masonry
• Splitting piles heads
• Rock splitting (e.g. in trench work)
• Secondary splitting of boulders
• Tunnel-driving work
• Expansion work in underground mining
• Granite block quarrying in the natural stone industry
• Chimney demolition
• Underwater demolition

Power Pack Specifications:

• Power Requirement: 115V – 20 Amp/ 220V – 10 Amp
• Fluid Capacity:
• Shipping Length: 18″
• Width: 18″
• Height: 24″
• Weight: 74lbs
