The XG1932AC Scissor Lift, a product of XCMG’s sophisticated engineering, is an elevating work platform designed to meet the demands of building construction professionals. With an operational height of 25ft 7in (7.8m), a machine width of 2ft 8in (0.81m), a rated load of 507lbs (230kg), and a platform extending length of 2ft 11in (0.9m), this machine delivers high performance in a compact design.

Notably, the XG1932AC Scissor Lift provides a maximum gradeability of 25%, ensuring reliable operation on varied terrains. With its zero-emission, environmentally friendly design, it ensures stable lifting and lowering operations. Moreover, it is user-friendly and requires minimal maintenance, making it an ideal choice for diverse industries, including factories, warehouses, airports, and stations.

Key features include:

• A sturdy 5’6″ x 2’5″ (1.67m x 0.74m) steel platform
• An extension deck with a length of 2’11” (0.9m)
• Front wheel drive for superior maneuverability
• 25% gradeability in the stowed/lowered position
• An accessible platform control equipped with a battery charge indicator and diagnostic display
• A manual platform lowering valve for enhanced safety
• Dual-control emergency stop activation, both at platform and ground level
• Front wheel multiple disc brakes and a manual brake release for assured stopping power
• Durable, non-marking solid tires
• Safety-enhancing pothole guards and a tilt alarm
• An hour meter for tracking usage
• A descent alarm for safe lowering operations
• An installed horn for alert communication
• Dual flashing beacons and a motion alarm for increased visibility and safety
• A load warning system to prevent overloading

The XG1932AC Scissor Lift embodies a perfect blend of performance, safety, and environmental sustainability. With its compact design, it is particularly suited for narrow working environments, providing unrivaled efficiency and adaptability.
