Introducing the XTF1256K Telehandler, a versatile piece of heavy-duty equipment engineered to tackle demanding tasks in construction and similar fields.

Engine
The XTF1256K is powered by the robust Cummins QSF3.8 engine, which achieves EPA Tier 4 Final standards. This is accomplished by combining Cummins’ Diesel Oxidation Catalyst with Selective Catalytic Reduction (DOC-SCR). The DOC-SCR system offers a common aftertreatment solution for power outputs ranging from 75 hp to 400 hp (56 kW to 298 kW). For specific applications, the QSF3.8 engine can also be paired with an SCR-only aftertreatment system.

Hydraulic System
The XTF1256K employs high-grade components for its hydraulic system. The main pump and main valves are supplied by Parker, renowned for their reliability and performance. The model for the main pump is P1075, while the main valve model is VP120.

Performance Specifications
The XTF1256K’s capabilities are impressive, providing:

Maximum capacity: 5,500 kg (12,125 lb)
Maximum lifting height: 17,100 mm (56 ft)
Maximum outreach: 13,150 mm (43 ft)
Maximum height lifting capacity: 2,267 kg (4,998 lb)
Maximum amplitude lifting capacity: 1,587 kg (3,499 lb)
Unladen lifting/lowering speed: 14/11 seconds
Unladen extension/retraction speed: 18/15 seconds
With its powerful engine, efficient hydraulic system, and remarkable lift capacities, the XTF1256K Telehandler stands out as a robust and reliable solution for challenging environments. It embodies exceptional strength, versatility, and reliability, delivering outstanding performance on every job.
