Ingersoll Rand – FA2B-24MX1 Air Tugger – 4000lb
This product is available to be rented.
This product is ready to be deployed underground.
- Make: Ingersoll Rand
- Model: FA2B-24MX1
- Capacity:
- 5,170lbs (1st layer)
- 4,000lbs (mid-drum)
- 3,260lbs (full drum)
- Operating Pressure: 90Psig
- Consumption Volume: 350CFM (@ rated pressure)
- Wire rope size: 1/2″
- Wire rope Capacity: 1362ft
- Line Speed (mid): 96fpm
- Features:
- Engineered frame for mounting winch
- “Football” style lubricator
- Hand Brake
- Drum Guard
- Whip check for airline
- Supplied with wire rope as needed
All of our Air Winches come with a fresh service and pull testing certificates showing a proof load of 125% of rated load has been applied and held by the manual brake.
Want to rent this product? Add it to your estimate.
